 Water Filtration
Site Navigation
|
  Carwash Reclaim
Use your existing in ground water collection tanks
Bioremediation and
Multi-Media filtration has been in existence since the dawn
of time, this is how nature has cleaned the earth and its
water for millions of years.
The use of multimedia
filters in combination with bioremediation is the perfect
match. The filters will not only catch the substrates to be
consumed by the bacteria but also the inorganic materials
bacteria will not consume. Multimedia filters are the perfect
biomass (collection point) for bioremediation products. Sand
and many types of silt are examples of items that bugs will
not eat. Multimedia filters will remove these contaminants
for back flushing to a removal point that is most convenient
for the operator of the carwash. Oils and grease must be caught
in a retention area (bioreactor) or coalescing system to allow
the enzymes to break them down and bacteria to consume them.
In the environment
and in industrial applications naturally occurring bacteria
are not present in sufficient numbers and the proper strains
of bacteria are not always available. No amount of enzymes
(proteins that breakdown the substrate for the bacteria to
consume) added to the water will change the type of bacteria
present. It’s true that the proper nutrients, both micro and
macronutrients are a great benefit to the bacteria supplementing
their diet and strengthening them. Combined with the correct
enzymes these nutrients shorten or eliminate the lag phase
in bacterial buildup (colonizing your system). Choosing a
proper Biodigester product is crucial to the success of the
system.
|
SPL24
This single polishing
loop system is designed to recycle and filter wastewater from
an existing in-ground pit or above ground tank and can utilize
many types of filter media. The filter media is specifically
selected for the carwash application. Consult us for media
recommendations.
3/4 Hp Single Polishing
Loop
Flow: 10 GPM Constant, 20 GPM Intermittent
Use: Tunnel, hand held carwashes
Requirements: adequate in-ground pits (sumps) or optional.
110 gal tank
|
SPL30
SPL30
This high flow,
single polishing loop system is designed to recycle and filter
wastewater from an existing in-ground pit or above ground
tank and can utilize many types of filter media. With its
higher flow rates multiple wash systems can be supplied with
recycled water. The filter media is specifically selected
for the carwash application. Consult us for media recommendations.
1.5 Hp Single Polishing
Loop
Flow: 50 GPM Constant, 70 GPM Intermittent
Use: Multiple- tunnel (friction), automatics and hand held
carwashes
Requirements: adequate in-ground pits (sumps) or optional
250 or 500 gallon above ground tank.
|
DPL30
This high flow, dual
polishing loop system is designed to recycle and filter wastewater
from an existing in-ground pit or above ground tank and can
utilize many types of filter media. With its higher flow rates
and dual filter media system, multiple wash systems can be
supplied with recycled water. The filter media is specifically
selected for the carwash application. Consult us for media
recommendations.
1.5 Hp Dual Polishing
Loop
Flow: 50 GPM Constant, 70 GPM Intermittent
Use: Multiple- tunnel (friction), automatics and hand held
carwashes
Requirements: adequate in-ground pits (sumps) or use two optional
250 or 500 gallon above ground tanks.
|
Specifications on
Systems That Use Underground Tanks
SPL24
Polishing Filtration to 10 GPM Continuous
SPL30 Polishing Filtration
to 50 GPM Continuous
DPL30 Dual Polishing Filtration
to 50 GPM Continuous |
|
